Hvof Torch

The tafa model 5220 is a kerosene fueled hp hvof gun that is used to achieve extremely high coating densities.

Hvof torch. Orifice diameter available in 3 32 1 8 5 32 and 3 16. Being line of sight technologies they could coat surfaces that the torch can see. Genie hvof torches. The hvof process combines fuel and oxygen to create rapidly expanding combustion gases inside a specially designed combustion nozzle.

This process converts much of its energy into mechanical force which accelerates the powder particles through the flame very quickly. 8 00 am 4 00 pm est find a location near you. Genie brand spare parts genie adapters and connectors. The egun is capable of operating at combustion chamber pressures up to 13 bar 188 psi.

Our internal diameter metal and carbide layers wc 10co 4cr and hastelloy type are non permeable to gas and liquid. This also allows for a typical coating thickness of 0 002 0 050. Flame spray is using the latest technology in miniaturize hvof and can coat a diameter as small as 70 mm. The unique design of this gun allows it to produce particle velocities of 3 300 to 3 900 fps which is significantly higher than any other gaseous fueled hvof device on the market today.

Since the maximum flame temperature is relatively close to the melting point of most spray materials hvaf results in a more uniform ductile coating. The jet kote 3000 torch has long been accepted as the premier torch for applications of hvof coatings. Genie gpdj 2700 hvof gun assembly genie gpdj hvof gun 8a genie gpdj hvof gun 9a contact our experts 1 317 240 2500. The kermetico ak id hvaf gun is a small rocket engine generating a jet of spray particles with a velocity that is generally in the range of 650 750 m sec.

Send a question or comment. The torch body is constructed from a one piece lightweight aluminum or 304 stainless steel mat. This general purpose water cooled hardfacing torch is used for numerous applications. Thanks to its unique stabilizer combustion head combustion chamber and nozzle design the this torch s truly one of a kind.

2 130 2 460 ft sec such particles form dense and tough layers. The egun is a liquid fuel hvof torch that utilizes ethanol as its fuel. This is 3 to 5 bar 43 73 psi greater than conventional kerosene hp hvof systems. Jet kote field service.

In the past only aps and flame wire torches could be mounted on extenders to enter small id. Genie hoses and cables. Hvaf has a maximum flame temperature of 3 560 to 3 650 f and an average particle velocity of 3 300 ft sec.
